Description
3.Tech index :
| NO. | Index | Unit | Type | Testing Method |
| A- | ||||
| 1 | Appearance | After molding,the surface should be flat,shinny and smooth,no bubbles or crack,color and foreign material achieves standard | ||
| 2 | Resistance to boiling water | No mushy,permit little color fade and purse | GB13454 | |
| 3 | Volatile matter | % | ≤4.00 | GB13455 |
| 4 | Water absorb(cold) | mg | ≤100 | GB1034 |
| 5 | Shrinkage | % | 0.60~1.00 | GB13454 |
| 6 | Distortion temperature | ℃ | ≥115 | GB1634 |
| 7 | Fluidity | mm | 140~200 | GB13454 |
| 8 | Impact Strength(notch) | KJ/m2 | ≥1.8 | GB1043 |
| 9 | Bending Strength | Mpa | ≥80 | GB9341 |
| 10 | Insulation Resistance after 24h in water | MΩ | ≥104 | GB1410 |
| 11 | Dielectric strength | MV/m | ≥9.0 | GB1408 |
| 12 | Baking Resistance | Grade | 1 | GB2407 |
| Molding condition:(Reference only) | ||||
| Temperature | 150~180 | |||
| Pressure | 25~40Mpa | |||
| Curing time | 0.24~0.3 min/mm | |||
4.Storage:
Kept in airy, dry and cool room.
Storage period: six months from the manufacturing date.
Test should be undertaken when expires. Qualified products can still be used.
5.Packing :
25kg in kraft paper bag or plastic knitting bag with inner wet proof plastic bag ,20mt in each 20′ FCL.
